SlimSAS Cable

Luxshare-TECH‘s SlimSAS is a robust and cost effective high speed connector and cable assembly solution. The SlimSAS products is specially designed for new generation SAS4.0 server and storage application with higher speed 24Gbps data rate and smaller size. The solution can also be used in PCIe Gen3/Gen4, 25G Ethernet and other potential applications.


FEATURES & BENEFITS
  • Support cable to board application: 1.0mm PCB card thickness
  • Multiple channels are optional: 4X/6X(38pos),8X/12X(74pos),more customized requirement available
  • Small size design with great robustness : Pitch 0.6mm connector and max 25N wrenching test
  • Excellent SI performance: Signal rates up to PCIe4 16Gbps, SAS 4.0 24Gbps and 25Gbps Ethernet
  • Compatible with many different industry standards and protocols including SAS, PCIe and 25G Ethernet
  • Straight, right angle, side exit and customization cable plug are optional
  • 85 ohm and 100 ohm impedances are optional
  • 30-34AWG cables are available for both discrete and ribbon cable
  • RoHS compliant. Halogen free is available on request
了解更多

Product Numbers Product Description
LA0SLXXX-SD-R Internal SlimSAS 4i Cable Assembly 1.0 m 30 AWG
LA0SLXXX-SD-R Internal SlimSAS 8i Cable Assembly 1.0 m 30 AWG
LA0SLXXX-SD-R Internal SlimSAS 4i Cable Assembly 0.7 m 32 AWG
LA0SLXXX-SD-R Internal SlimSAS 8i Cable Assembly 0.7 m 32 AWG
LA0SLXXX-SD-R Internal SlimSAS 4i Cable Assembly 0.5 m 34 AWG
LA0SLXXX-SD-R Internal SlimSAS 8i Cable Assembly 0.5 m 34 AWG
