S-SFP/U-SFP

Luxshare-TECH Super SFP and Ultra SFP high speed I/O connector and cage support one channel at 25Gbps and 56Gbps in the high-density package(SFP). Luxshare-TECH Super SFP and Ultra SFP I/O connector is a standard 20-position gold finger interface and SMT footprint of excellent SI performance. And there are diverse types of cage available including 1xN and 2xN that could meet belly to belly easily.


FEATURES & BENEFITS
  • EMI spring for cages provide excellent-EMI protection
  • Solder and Press Fit cage configurations available
  • Support 25 Gbps/Channel for Ethernet application and 28Gbps/channel for FC application
  • Backwards compatible with SFP/SFP+ Ethernet and FC application
  • Backwards compatible with SFP/SFP+ transceiver module and cable assembly, same mating interface and EMI cage dimensions
  • Enhanced EMI cage design provides excellent EMI-protection and thermal performance
了解更多

Product Numbers Product Description
PZP020-7500-001-1R Super SFP28 conn, 20pin, SMT
PZP020-7500-001-1R S-SFP CONNECTOR,20P,Au 30u",SMT,for EMC
PDPB22-6300-000-1H S-DSFP28 Conn, 22P, Au30u", SMT
PSFC11-E220-05S-0R SFP+1X1 CAGE WITH 13.5MAX HS, w/o LP
PSFC11-E320-05S-0R SFP+1X1 CAGE WITH 15.8MAX HS, w/o LP
PSFC14-E300-09S-0R SFP+1X4 CAGE w 18MM HS, w/o LP
PSFC18-E322-00S-0R SFP+ 1X8 CAGE, w two LP, w HK 3.5W
PSPB20-6300-000-1R SFP+ conn, 10G, SMT
PSPC11-E000-0AS-0R SFP+ 1X1 CAGE, w/o HS & LP
PSPC11-E200-000-0R SFP+ 1X1 CAGE, w/o HS & LP
PSPC11-E200-100-0R SFP+ 1X1 CAGE, DIP, close top, H3.05, w/o HS&LP
PZPC11-E200-000-0R S-SFP 1X1 CAGE, 3 EON in rear-end, w/o heatsink, w/o light pipe, stainless EMI finger
PSPC11-9200-000-0R SFP+ 1X1 CAGE,3 EON in rear-end, w/o heatsink, w/o lightpipe
PZPC11-E300-000-0R S-SFP 1X1 CAGE,3 EON in rear-end, w/o heatsink, w/o lightpipe
PZPC13-E300-000-0R S-SFP 1X1 CAGE, 3 EON in rear-end, w/o heatsink, w/o lightpipe, 1degree up
PZPC16-0100-099-0H SFP28 1X6 CAGE w HS, w/o LP, SMT
PZPC16-E200-000-0R DSFP28 1X6 CAGE, open top, w HS(H=14.3MM), 6Ports w dual LP
PZPC16-E302-000-0R S-SFP 1X1 CAGE,3 EON in rear-end, w/o heatsink, w/ lightpipe
PZPC28-E300-000-0R S-SFP 1X2 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe
PZPC28-E300-010-0R S-SFP 1X2 CAGE,2 EON in rear-end, w/o heatsink, w/ lightpipe, window open on the top
PZPC28-E310-010-0R S-SFP 1X2 CAGE,2EON in rear-end, w/ 13.65mm heatsink, w/o lightpipe
PZPC28-E340-010-0R S-SFP 1X2 CAGE,2 EON in rear-end, w/ 13.8mm heatsink, w/o lightpipe
PZPC28-E700-000-0R S-SFP 1X2 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe, EM finger on the bottom
PZPC28-E700-010-0R S-SFP 1X2 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe, EM finger on the bottom, window open on the top
PZPC41-E200-000-0R SFP28 1X4 CAGE, w/o HS & LP
PZPC48-E300-000-0R S-SFP 1X4 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe
PZPC48-E300-010-0R S-SFP 1X4 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe, EM finger on the bottom
PZPC48-E3B0-010-0R S-SFP 1X4 CAGE,2 EON in rear-end, w/ 12mm heatsink, w/o lightpipe
PZPC48-E340-010-0R S-SFP 1X4 CAGE,2 EON in rear-end, w/ 14.3mm heatsink, w/o lightpipe
PZPC48-E700-000-0R S-SFP 1X4 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe, EM finger on the bottom
PZPC48-E700-010-0R SFP28 1X4 CAGE, /wo HS & LP, holes on top
PZPC68-E300-000-0R S-SFP 1X6 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe
PZPC68-E700-000-0R S-SFP 1X6 CAGE,2 EON in rear-end, w/o heatsink, w/o lightpipe, EM finger on the bottom
PZPC68-E702-000-0R S-SFP 1X6 CAGE,2 EON in rear-end, w/o heatsink, w/ lightpipe
PZPC84-E705-001-0R S-SFP 1X8 CAGE,2 EON in rear-end, w/o heatsink, w/ lightpipe, EM finger on the bottom
